VDO : TEMPERATURE SENSOR (เซนเซอร์วัดอุณหภูมิ)
NAME: VDO - TEMPERATURE SENSOR
Standard Specification:
Temperature measuring range: +50°C to +150°C ; +40 °C to +120 °C
Minimum - Maximum operating temperature: -40 °C to +180 °C ;-40 °C to +150 °C
Thread: M14 x 1.5 ; M16 x 1.5 ; 1/4-18 NPTF
Sender element length + thread (L): 29 mm ;15 mm
Sensor diameter: 9 mm
Torque: 20 Nm ; 30 Nm
Temperature medium: Coolant - Water - Air - Engine oil - Transmission oil - Fuel
Operating voltage: 6 - 24 V DC
Resistor range: 322.8 - 18.6 Ohm ;287.4 - 22.7 Ohm
Temperature sensor signal: Single-Pole common ground ; Dual-Pole insulated return
Warning contact: None
Optional warning contact: VDO A2C59510886 Makepoint Switch
Temperature sender connector: AMP Male 6.3 x 0.8 mm
Product:
1.VDO Oil Temp Sensor
Temperature range: +50°C to +150°C ; +40 °C to +120 °C
Thread: M14 x 1.5 ; M16 x 1.5 ; 1/4-18 NPTF
Sender resistance range: 322.8 - 18.6 Ohm
Sensor signal: 1-pole common ground ; Dual-Pole insulated return
No warning contact
2.VDO Water Temp Sensor
Temperature range: +40 °C to +120 °C
Thread: M14 x 1.5
Sender resistance range: 287.4 - 22.7 Ohm
Sensor signal: 1-pole common ground
No warning contact
