Engines are designed to operate at a minimum/maximum pressure for safe operation. The pressure will vary depending on the engine revolutions, but continual low presure could be the sign of a serious problem. AIS oil pressure aguge have been designed to monitor oil pressure in either the engine or gearbox and to warn ther user of any possible problem, AIS oil pressure gauge are supplied with a complete wiring kit, consisting of terminals, internal lights (red and green) mounting brackets and nuts.

1.OG/500
● Part No. OG/500
● Range: 0-500kPa
● Voltage: 12/24 Volt
● Diameter: 52mm (2")
use with Part No. OS/500/1 Sensor
● Range: 0-500kPa
● Type: 1 Pole
● Thread: 1/8" 27 NPTF
-----------------------

DAVEN CODE: 110007

2.OG/750
● Part No. OG/750
● Range: 0-750kPa
● Voltage: 12/24 Volt
● Diameter: 52mm (2")
use with Part No. OS/750/1 Sensor
● Range: 0-750kPa
● Type: 1 Pole
● Thread: 1/8" 27 NPTF

-----------------------

DAVEN CODE: 110008

3.OG/1000
● Part No. OG/1000
● Range: 0-1000kPa
● Voltage: 12/24 Volt
● Diameter: 52mm (2")
use with Part No. OS/1000/1 Sensor
● Range: 0-1000kPa
● Type: 1 Pole
● Thread: 1/8" 27 NPTF

-----------------------

DAVEN CODE: 110009
