VDO : PRESSURE SENSOR (เซนเซอร์วัดแรงดัน)
NAME: VDO - PRESSURE SENSOR
Standard Specification:
● Pressure measuring range: 0 - 10 Bar ; 0 to 28 Bar
● Maximum pressure: 30 Bar during 2 seconds ; 50 Bar during 2 seconds
● Thread: 1/8 - 27 NPTF ;M14 x 1.5 ;
● Length thread + nut (L1): 19.5 mm
● Thread length (L2): 11 mm
● Torque: 30 Nm
● Operating temperature: -25 °C to +100 °C
● Pressure medium: Oil - Fuel - Air
● Operating voltage: 6 - 24 V DC
● Resistor range: 5 - 90 Ohm
● Pressure sensor signal: Dual-Pole insulated return
● Warning contact: None
● Optional warning contact: VDO A2C59510886 Makepoint Switch
● Special application: For 2 gauges Flybridge
● Pressure sender connector: M4 AMP Male 6.3 x 0.8 mm
Product:
1.VDO Oil Pressure Sensor (2 terminals)
● Pressure range: 0 to 10 Bar
● Thread: 1/8 - 27 NPTF
● Sender resistance range: 5 - 90 Ohm Dual
● Sensor signal: 2-pole insulated return
● No warning contact
2.VDO Oil Pressure Sensor (1 terminals)
● Pressure range: 0 to 10 Bar
● Thread: M14 x 1.5
● Sender resistance range: 10 - 184 Ohm
● Sensor signal: 1-pole common ground
● No warning contact
3.VDO Oil Pressure Sensor 400PSI
● Pressure range: 0 to 28 Bar
● Thread: 1/8 - 27 NPTF
● Sender resistance range: 5 - 90 Ohm Dual
● Sensor signal: 2-pole insulated return
● No warning contact
