Specification:
• Characteristics
– Rest position : 30°, 35°, 45°
– Travel angle : 22°
– Two “built-in” return springs
– Die cast aluminium treadle support and mounting plate
– IP66 or IP69K
– Storage temperature : -40°C to +95°C
– Operating temperature : -40°C to +85°C
– Connector : AMP – 6 pins – waterproof (IP69)
• Standards
– FMVSS 124
– 72/245/EEC
– E1 number 03 5754
• Output Signals
The output values are programmable and hence can be adapted to the customer’s specifications. Electronic Throttle Controls can be connected directly to the engine management system, or engine Electronic Control Module.
• Options
– Brake spring
– Rubber cover
– Twin sensors (up to 4 output signals)
– Mechanical kick down
– CAN J1939
– Connector kit or customized wire harness

Product:
1. Part N.: 962 330 02
Pedal Throttle 30

----------------------

DAVEN CODE: 370015
