GUAGES
NAME: VDO - TACHOMETER W/ HOURMETER (SINGLEVIU)

Standard Specification:
● Tacho Measurement Range: 0 - 4.000 RPM
● Warning Light: Multi LED Programmable
● Operating Voltage: 8 - 32 Volt DC
● Packaging: SingleViu Single Piece Retail
● Application: VDO Engine Monitoring
● Signal Digital: CANBus J1939: 61444-190-0x17
● Signal Analogue: Tacho Impulse Signal
● Serie: VDO SingleViu CANBus-Analog
● Dial Illumination: Multi-Colour Programmable
● Dial Scale: Single
● Lens: Mineral Glass - Anti-Fog
● Country Of Origin: China
● Color: Black
● IP Class Front: IP67 (IEC 60529)
● Input: CAN Bus & Analog
● Installation Dimension: 80 Mm - 3 1/8 Inch
● Functionality: Tachometers Multifunction
● Bezel Interchangeable: Yes - Special Tool Required
● Bezel Model: Black Triangle
● Connector Type: Molex 8 & 12-Pin CANBus
● Communication: CANBus J1939 Or Analogue

Product:
1.VDO Tachometer 4.000 RPM (SingleViu)
● Black - Hole: 80-85 mm - 3 1/8 - 3 1/3"
● Operating voltage: 8-32 Volt DC
● Range: 0 - 4.000 RPM
● Input signal: Pulses
● CANBus input: 61444 - 190 - 0x17
● Connection cable included

---------------------

DAVEN CODE: 120085
