TEMPERATURE SWITCH

NAME: NASON - HT TEMP SWITCH

Features:

• Utilizes bellows mechanism to sense temperature

• High-quality snap-action switch

• Factory preset

• Shock and vibration resistant

• Available in a wide range of configurations

• NEMA 4, 13

Operating Specifications:

• Set Point Range: 40° — 300°F (4° — 149°C)

• Set Point Tolerance: ±5°F (2.8°C)

• Maximum Operating Temperature: 100°F above set point (325°F max)

• Differential: 8 — 16°F

• Current Rating: 10 A @ 125/250 VAC 5 A @ 30 VDC

• Media Connection: Standard: Brass (Optional: 303 SS, 316 SS)

• Circuit FormL SPST-NO, SPST-NC or SPDT

• Maximum External Pressure: 500 PSI

• Unit Weight: .23 lbs

• Installation Torque: 15 ft lbs Smaller than 3/8" NPT Male = 5 — 10 ft lbs

Product:

1.Nason HT Temp switch

• Media Connection:1/2" NPT Male ; 1/4" NPT Male

• Circuit Form: C SPDT

• Fixed Set Point: 205°F ; 212°F ; 220°F

• Set Point Direction: R Rising

• Electrical Options: HR DIN43650A Connector

-------------------------

DAVEN CODE: 340001
